Pi 3.14 Bass Trap - Low Frequency Sound Absorption Panel

Pi 3.14 Bass Trap - Low Frequency Sound Absorption Panel
Pi 3.14 Bass Trap - Low Frequency Sound Absorption Panel
Pi 3.14 Bass Trap - Low Frequency Sound Absorption Panel
Pi 3.14 Bass Trap - Low Frequency Sound Absorption Panel
Pi 3.14 Bass Trap - Low Frequency Sound Absorption Panel
Acoustic treatment
Acoustic treatment
Best seller
Best seller
Customisable
Customisable
Guaranteed result
Guaranteed result
Indoor use
Indoor use
Made in EU
Made in EU
Original
Original
T02-Caribbean Sand
T02 Caribbean Sand
T03-Todays Herald
T03 Todays Herald
T04-Coffeelandia
T04 Coffeelandia
T05-Bitter Chocolate
T05 Bitter Chocolate
T06-Rubbies are Red
T06 Rubbies are Red
T07-Violet Candy
T07 Violet Candy
T08-Baby Elephant
T08 Baby Elephant
T09-Mr. Grey
T09 Mr. Grey
T11-Nicotiana Rustic
T11 Nicotiana Rustic
T10-Lead Arrow
T10 Lead Arrow
T13-Jet Set
T13 Jet Set
T12-Frog`s Romance
T12 Frog`s Romance
T01-Black Cat
T01 Black Cat
T14-Stone Breaker
T14 Stone Breaker
T15-Soft Powder
T15 Soft Powder
T16-London Mist
T16 London Mist
T17-Smokey Eyes
T17 Smokey Eyes
T18-True Turquise
T18 True Turquise
T19-My Father`s Jacket
T19 My Father`s Jacket
T20-Chocolate Souffle
T20 Chocolate Souffle
T21-Moroccan Sun
T21 Moroccan Sun
T22-Purple Haze
T22 Purple Haze
Buy Now
Request a Quote
Offer for
Pi 3.14 Bass Trap - Low Frequency Sound Absorption Panel

(Please fill all the required fields, marked with *.)

How do you prefer us to contact you?


This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

The Pi 3 14 acoustic foam bass trap is exclusively designed to provide effective low-frequency absorption between 125-250Hz. The wooden face plate comes in 7 mm thickness, and has 3.14% of perforation made of 15 cross shaped openings. The openings are in the shape of "cross", are more effective than the standard round holes. The perforated face plate and the body of acoustic foam act as "Helmholtz resonator".

To get the complete ultimate look, we have covered the bass trap with an elegant black acoustic fabric that gives the final touch of the “P” bass trap. It is designed for application in the corners of the room, where excess sound energy in this spectrum is accumulated.

Pi 3 14 acoustic foam bass trap is suitable for:

  • Recording and broadcast studios
  • Listening rooms
  • Home theaters
  • Conference and teleconference rooms
  • Offices
  • Rehearsal rooms
  • Call centers
Acoustic Performance
Technical data
MaterialPerforated wooden plate and acoustic fabric (face)
Designblack fabric with seeable cross perforation
Dimensions front plate420 x 1000 mm
Side wall300 x 1000 mm
Weight3 kg per unit
Perforation3,14%
Installationcorner glued
